Weldable Vent

Acoustic Vents

Technical Data
WEP:20-150kPa
Air Flow: 2000-25000ml/min/cm2 at 7kPa.
Insertion loss: <1.0 dB.
IP ratings: IP64, IP65, IP66, IP67, and IP68
Operating temperature: -40℃ to +85℃.
Send Inquiry
Chat Now
Description
Technical Parameters
Introduction
Introduction

Sinceriend acoustic air vents are designed exclusively for industrial electronic equipment, providing outstanding acoustic performance and watertight protection for electronic enclosures while also prolonging the service life of acoustic devices such as walkie-talkies.
Sinceriend ePTFE membranes have varying IP ratings and provide high-quality acoustics performance.

2_



Body-worn cameras and walkie-talkies are crucial tools for public safety officers such as traffic cops and firefighters. When exposed to a lot of dust, sweat, and rainfall, product performance suffers. As a result, waterproofing and product reliability are held to high standards. However, increasing the level of shielding frequently results in reduced acoustic performance as well as a detrimental impact on sound transmission.

Sinceriend acoustic air vent protects microphones on body-worn cameras and walkie-talkies from damage while still allowing clear audio transmission. This greatly improves the experience of law enforcement personnel.

2



Key Features

High level of severe water spray protection.
Transmission loss (<1.0 dB).
Customized sizes are available.
High audio consistency.
Excellent long-term reliability.
IP rated vents with low bulk for efficient sound transmission.



We can provide standard sizes or custom sizes on request.

8

9
